Cath Lab Equipment Moving: Relocating Angiography Systems and Interventional Imaging Suites
Cardiac catheterization laboratories contain some of the most complex and expensive imaging equipment in a hospital. A ceiling-mounted angiography C-arm system, hemodynamic monitoring consoles, contrast injectors, intravascular ultrasound systems, and electrophysiology mapping equipment work together as an integrated interventional suite. Relocating a cath lab means moving this entire integrated system while maintaining the relationships between components that make the suite function as a clinical unit.
Ceiling-Mounted C-Arm Systems
The angiography C-arm is the centerpiece of most cath labs. Ceiling-mounted systems from Siemens, Philips, and GE Healthcare hang from a structural ceiling mount that supports the weight of the C-arm, the X-ray tube, and the flat-panel detector. Deinstallation requires disconnection from the ceiling mount, careful lowering of the C-arm to floor level, and structural assessment of the ceiling mount at the destination to confirm it can support the system.
The flat-panel detector on the C-arm is a high-value component sensitive to shock and vibration. STSI packages the detector with dedicated vibration isolation and transports it separately from the mechanical components of the C-arm when the move profile warrants this level of protection.
Hemodynamic Monitoring Systems
Hemodynamic monitoring consoles are connected to the hospital's clinical information system and may be integrated with the angiography system for synchronized data capture. Deinstallation requires coordination with the facility's IT team to properly disconnect network interfaces and the biomedical engineering team to document all integration settings.
Floor Load Considerations
Cath lab equipment, particularly the ceiling-mounted C-arm system, creates concentrated floor loads that require structural assessment at the destination. The C-arm ceiling mount transfers the full weight of the system through the ceiling structure to the building's structural frame. STSI coordinates with structural engineers to confirm that the destination room's ceiling and floor can support the system before scheduling delivery.
Radiation Shielding
Cath labs include radiation shielding in walls, floors, ceilings, windows, and doors to protect adjacent spaces from scatter radiation during procedures. When a cath lab relocates to a new room, the destination must have equivalent shielding installed and verified before the equipment arrives.
Post-Move Integration Testing
After installation, the entire cath lab suite must be tested as an integrated system. STSI coordinates post-move testing with the OEM service teams, the facility's biomedical engineering department, and the interventional cardiology clinical team to confirm that the suite is fully operational before the first procedure.
Get a quote for your cath lab equipment relocation from STSI. https://spectransport.com/industries/medical-equipment
